•Thompson England 8kVA Silent Generator with ATS - Diesel Single Phase (Model: DG-8000-S)

•The Thompson England 8kVA Silent Diesel Generator (DG-8000-S) is a compact, fuel-efficient, and low-noise power solution designed for home backup, small businesses, and commercial applications where noise reduction is essential. Rated at 5.5kW continuous (7kVA) with a maximum output of 6.5kW (8kVA), this unit is powered by the reliable 188FE air-cooled diesel engine. It features an integrated Automatic Transfer Switch (ATS) for seamless power backup during outages, automatically starting and stopping the generator without manual intervention. The silent canopy significantly reduces operational noise, making it ideal for residential areas, offices, clinics, and small retail shops.

•Model / SKU: DG-8000-S with ATS / THO-8-D-SILENT

•Power Output (Max): 8 kVA (Approx. 6.5 kW)

•Rated Power (Continuous): 7 kVA (Approx. 5.5 kW)

•Phase: Single Phase (220V - 240V)

•Frequency: 50 Hz

•ATS (Auto Transfer Switch): Yes (Included - Automatic mains failure start)

•Engine Type: 4-Stroke, Air Cooled, Direct Injection Diesel

•Engine Model: 188FE (Single Cylinder)

•Displacement (cc): Approx. 418cc - 456cc (Typical for 188FE series)

•Cooling System: Forced Air Cooled

•Fuel Type: Diesel (Automotive / Industrial grade)

•Fuel Consumption: Approx. 1.5 - 2.0 L/hr @ 50% load

•Starting System: Electric Start (ATS Auto Start + Key Start)

•Recoil Backup: Yes (Manual pull start as backup)

•Low Oil Shutdown: Yes (Engine protection)

•Fuel Tank Capacity: Approx. 12.5 - 15 Liters

•Run Time @ 50% Load: Approx. 6 - 8 Hours

•Alternator Type: Brushless with AVR (Automatic Voltage Regulation)

•Enclosure: Silent Type (Soundproof / Low Noise Canopy)

•AC Outlets: 2x 13A UK Standard Socket, 1x 16A Industrial Socket

•Control Panel: Digital Display (Voltage, Frequency, Hour Meter, ATS Status)

•Circuit Breaker: Yes (Overload protection)

•Noise Level: Approx. 68 - 72 dB @ 7m (Silent enclosure rating)

•Frame Type: Heavy Duty Powder Coated Steel Tube Frame with Anti-Vibration Mounts

•Wheel Kit: Heavy Duty Wheels + Tow Handle (Included)

•Net Weight: Approx. 100 - 120 kg

•Dimensions (L x W x H): Approx. 850 x 550 x 700 mm

•Battery: 12V 32Ah - 45Ah (Included - for electric start)

•24Months Warranty Support

•Spare Parts Available

•ATS Function Note: The Automatic Transfer Switch continuously monitors mains power. Upon mains failure, the ATS automatically starts the generator within seconds. When mains power is restored, the ATS transfers the load back to the grid and shuts down the generator after a cool-down period. No manual intervention required.

•Diesel + Silent + ATS Advantages:

•Diesel: Lower fuel cost, longer engine life, no spark plugs or carburetor

•Silent Canopy: Reduces noise by 10-15dB compared to open-frame generators

•ATS: Automatic backup - ideal for unattended operation (offices, clinics, server rooms)

•Typical Applications:

•Home backup (lights, fridge, TV, fans, phone charging)

•Small office / retail shop

•Clinic / dispensary (vaccine refrigerators, diagnostic equipment)

•Salon / barbershop

•Small restaurant (freezers, lighting, point-of-sale systems)

•Security / gate automation backup

•Telecommunications tower (small cell site)
